Technical parameter:
Model | WXR-320 | WXR-420 |
Cutting speed | 120m/min | 120m/min |
Cutting precision | 士0.10mm | 士0.10mm |
Maximum width | 320mm | 420mm |
Maximum unwinding diameter | 550mm | 550mm |
Double rewinding diameter | 350mm | 350mm |
Input Voltage | 380v | 380v |
Motor Power | 5KW | 5KW |
Machine dimension | 2000*1000*1900mm | 2000*1100*1900mm |
Machine weight | About 1000kg | About 1200kg |
Main features:
Compared with the round cutter die-cutting machine faster, more efficient, simple operation, smooth operation;
With automatic meter counting, automatic stop, photoelectric eye deviation correction and other functions;
It is a four-axis coil changing and cutting machine with cutting function.
With high precision round cutter die-cutting system; Used for blank sticker, die - cutting, cutting can be completed at one time.
Scope of application:
◎Suitable for cutting protective film, PET, insulating material, mylar, industrial tape, adhesive products and various electronic materia
